LAB 508 UV-VIS™ BENCHTOP

Description

RELIABLE, BENCHTOP UV-VIS ANALYZER

For Single Channel Spectroscopic Analysis

Our GUIDED WAVE™ LAB 508 UV-VIS™ Full Spectrum Benchtop Analyzer is a single channel, fiber optic, UV-VIS spectrometer system designed for use in lab environments.

The GUIDED WAVE LAB 508 UV-VIS Full Spectrum Benchtop Analyzer comes in a NEMA 4x enclosure. Up to 16 parameters may be monitored on each channel making it suitable for many applications. It has a built-in computer control unit with optional touch screen for convenient user interface.

Low cost per point – up to 16 parameters
Less maintenance – light source lasts up to two years
Safe – no hazardous chemicals inside the analyzer
Model services available
Lab-quality validation results (to ASTM standards)

FEATURES

Rapid data collection with enhanced diode array miniaturized optical bench
Analyzer control program developed in LabVIEW™ featuring customizable settings and trending capability
Modbus communications with built-in event setup. Optional Opto 22 panel and communications for 4-20 mA analog and discrete interfacing
Compatible with our proven probe and flow cell products
Full spectrum scanning, 200 nm to 850 nm
Calibration Model Ready
Simple B-Vector and formulaic models
Built-in Color Analysis
File formats – GW ASCII/BINARY and Grams SPC

APPLICATIONS

Lab and other color coordinates
Solvent recovery purity
Maleic acid in tetrahydrofuran (THF)
Trace (ppm level) impurities in wash water; Clean-In-Place
Polynuclear aromatics (PNA’s) in middle distillates
Phenol in cyclohexane
Sodium hypochlorite in bleach solutions
Aromatics in monomers
Sorbic acid in water
Ferrous chloride in acid
Acetonitrile purity
Hypochlorous acid
Antioxidants in polymers and plastics
Color and clarity of varnishes

INDUSTRIES

Here is a list of industries that use the GUIDED WAVE LAB 508 UV-VIS Full Spectrum Benchtop Analyzer:

Food and beverage production
Chemical production
Pharmaceutical manufacturing
Agriculture
Biofuels
Petrochemicals
Polymer production
Environmental monitoring and testing

These industries require accurate and reliable analysis of liquids and solids for various purposes, such as quality control, research and development, and product testing.

The GUIDED WAVE LAB 508 UV-VIS Full Spectrum Benchtop Analyzer is a non-invasive and non-destructive tool that provides rapid and precise analysis of a wide range of substances. It can be used to analyze liquids and solids, such as food and beverages, chemicals, polymers, and agricultural products. The system is easy to use and can be integrated into existing laboratory workflows.
