Paperless Recorder PHF
Compact front panel: 144 x 160 mm
Up to 6 channels for thermocouples, RTD, voltage, or current input
- Data saving on CompactFlash
For example, the data of 4 years’ worth can be stored on 512 MB card. - Data viewer and parameter loader software provided as standard
- Ethernet (option)
allows you to use FTP, web server, e-mail, etc. - Lithium-ion battery driven version available
Battery life: approx. 10 years - Quick search and display of past data
Just scroll the screen to check the past data - 3 or 6 input channels
Description
| General specifications | Mounting method | Panel mount |
|---|---|---|
| Dimensions | 160 (H) × 144 (W) × 185 (D) mm | |
| Power supply voltage | 100–240 V AC, 50/60 Hz | |
| Power consumption | Approx. 42 VA (at 240 V AC) | |
| Terminal | M3 screw terminal | |
| Input section | Number of input | 3 or 6 (as specified by order) |
| Measurement cycle | 100 ms | |
| Input signal | Thermocouple (type B, R, S, K, E, J, T, N, W, L, U, or PN) RTD (Pt100) DC voltage (50 mV, 500 mV, or 5 V) DC current (with shunt resister) |
|
| Burnout function | Provided as standard for thermocouple or RTD input | |
| Display unit | Display | 5.7″ TFT color LCD (320 x 240 dots) with automatic display off function |
| Life of backlight | 50,000 hours (at 20°C) | |
| Display contents | Trend, bar graph, digital display, event summery, tag, scale Historical trend, parameter, Ethernet log |
|
| Recording function | Storage medium | CompactFlash |
| Recording capacity | 2 GB max. | |
| Data saving cycle | Links to refreshment cycle of the trend display | |
| Trend data | Average, instantaneous value, or maximum and minimum value are saved. | |
| Event data | Alarm data, message data, power on and off are saved. | |
| Setting data | Parameter setting is saved. | |
| Data format | ASCII (readable by Excel) Binary (not readable by Excel) |
|
| Storage capacity | About 4 years’ worth at a display refresh cycle of 30 seconds (ASCII, 6 channels, 512 MB CompactFlash) | |
| Memory consumption | The display unit displays how much memory has been used. A user can select whether to stop recording or to delete stored file. | |
| Calculation function | Difference between channels, square root extraction | |
| Alarm | Number of settings | Up to 4 alarms for each channel |
| Alarm type | High/low limits | |
| Indication | Alarm status is displayed on digital display unit when an alarm occurs. Histories are displayed in the alarm summary. |
|
| Relay contact output | up to 10 (option) | |
| Performance | Indication accuracy | ±(0.15% + 1 digit) of input range |
| Indication resolution | 0.1°C | |
| Reference junction compensation error |
±0.5°C | |
| Others | Memory backup | Parameter settings are saved to the internal nonvolatile memory. The clock is backed up by a built-in lithium battery. Trend data is stored in CompactFlash with no back-up. |
| Option | Alarm output | Relay output, 10 points |
| Digital input | No-voltage contact input, 5 points | |
| Communication | Ethernet | |
| Accessories | CD-ROM (parameter loader software, instruction manual), panel mounting bracket, noise filter for power cable |
