Spark™ H2O
TIGER OPTICS™ PPB-Level Trace Moisture Detection CRDS Analyzer
Description
CRDS LASER-BASED ANALYZER
FOR EASY H2O ANALYSIS: 12 PPB TO 2000 PPM
For the first time, powerful advanced spectroscopy is available at a popular price for a host of applications, from quality assurance to cylinder filling, as well as welding, medical, industrial and high-purity gas production; bulk delivery and distribution transfer points; and more. Say goodbye to cumbersome, complex, costly and labor-intensive mid-20th century technology. Gone is the need for calibration, spare parts, cramped ranges, and worries about drift and downtime. Our TIGER OPTICS™ Spark™ H2O is fast, easy to start up and operate.
THE COMPACT, AFFORDABLE SPARK H2O OFFERS:
- Powerful, proven Cavity Ring-Down Spectroscopy (CRDS) technology
- Self-tuning and auto-calibration
- Extremely low cost of ownership
- Ethernet, 4–20mA and RS-232 connectivity
- Fast response, with low gas consumption
- H2O analysis over a vast range: 12 ppb to 2000 ppm!
GET MORE OUT OF YOUR SPARK WITH OUR OPTIONAL ADD-ON PACKAGES:
- Speed+
- Dew Point Measurement
- Linear Fit Point
- Annual Performance Verification
APPLICATIONS
DETECTION CAPABILITY
| Detection and Matrix | Range | LDL (3σ) | Precision (1σ) @ zero |
|---|---|---|---|
| H2O in N2 | 0 – 2000 ppm | 12 ppb | 4 ppb |
| H2O in O2 | 0 – 1000 ppm | 6 ppb | 2 ppb |
| H2O in Ar | 0 – 900 ppm | 4.5 ppb | 1.5 ppb |
| H2O in He | 0 – 450 ppm | 3 ppb | 1.0 ppb |
| H2O in H2 | 0 – 1750 ppm | 7.5 ppb | 2.5 ppb |
| H2O in Clean Dry Air (CDA) | 0 – 1800 ppm | 10 ppb | 3 ppb |
| H2O in Ne | 0 – 450 ppm | 30 ppb | 10 ppb |
| H2O in Kr | 0 – 1100 ppm | 5.5 ppb | 1.8 ppb |
| H2O in Xe | 0 – 1300 ppm | 7.5 ppb | 2.5 ppb |
| H2O in CO | 0 – 2400 ppm | 15 ppb | 5 ppb |
| H2O in CF4 | 0 – 1300 ppm | 9 ppb | 3 ppb |
| H2O in NF3 | 0 – 1800 ppm | 9 ppb | 3 ppb |
| H2O in SF6 | 0 – 1300 ppm | 15 ppb | 5 ppb |
We also offer a new CRDS analyzer performance upgrade. Implementing our new intelligent dynamic data processing, the Speed+™ Analyzer Performance Upgrade Software adjusts your analyzer’s response automatically and in real-time to deliver the best performance. Benefits of Speed+ for your operations include real-time process control to ensure quality, as well as faster throughput and increased capacity to improve efficiency and profitability.
Serani™ Max Analyzer Interface Software allows you to have remote access from your computer or laptop for our latest CRDS generation analyzers, such as the Halo KA Max and T-I Max. The Windows-based software package communicates with the analyzer through Ethernet and allows full control of the system conveniently from your desk.
